Denor Rotary Mechanical Bar Screen — a wastewater screening solution designed to remove large debris from channel flow efficiently.
Also known as a rotary type bar screen machine, it keeps your treatment system running smoothly by catching solids before they cause problems downstream.
Built to fit your project — exactly. Each unit is customized based on: Flow rate, Channel width and depth, Rake tooth spacing
Ready to spec a auto mechanical bar screen for your project? For more product information or pricing, please email us at denor@denorgroup.com or leave a message via WhatsApp so we can assist you promptly.
Main benefits of rotary mechanical bar screen
Fully automatic control, simple and safe operation.
High performance & high efficiency of separation.
Quick install - shipped fully assembled and ready to operate.
Low energy consumption, no noise.
Outstanding corrosion resistance.
Stable and reliable operation.
Easy maintenance.
Main applications
Municipal projects
Industrial wastewater treatment
Irrigation pumping stations
Power plants
Industrial water recycling and reuse
Product Description
Technical Data
Applications
The Mechanical Bar Screens, also known as a Mechanical Rakes or Mechanical Screens, are automated filtration devices used in water and wastewater treatment plants. It automatically intercepts and removes suspended, large solid debris from water flow using mechanical means, thus protecting the stable operation of subsequent treatment equipment and processes.
Our mechanical bar screen are mechanical fully automatic screen used for liquid/solid separation in the pre-treatment stage. It is mainly applied for municipal, district WWTP pre-treatment stage, municipal rainwater and sewage pumping station, waterworks and cooling water from power plant. This unit has been widely applied in textile, printing and dyeing, food, aquatic product, paper-making, slaughter, tannery wastewater treatment process.
| Frame Width | 500 mm ~ 3000 mm (customized by channel width) |
| Available clearance | 2, 3, 5, 8, 10, 20, 30, 40, 50 mm(optional) |
| Mounting Angle | 75° (Customized) |
| Voltage | 220V 380V (Customized) |
| Slagging Height | 800 mm from floor level |
| Material | Stainless steel or cast iron (Customized) |
| OEM/ODM | Accept |
|
Model |
Power |
Water flow volume (m3/h) |
Screen Width (B1) |
Channel Width (B) |
||||
|
|
|
1mm |
3mm |
5mm |
10mm |
15mm |
|
|
|
DNRGS-300 |
0.37KW |
150 |
300 |
450 |
460 |
460 |
300 |
400 |
|
DNRGS-400 |
|
170 |
340 |
420 |
510 |
540 |
400 |
500 |
|
DNRGS-500 |
0.55KW |
240 |
480 |
590 |
730 |
750 |
500 |
600 |
|
DNRGS-600 |
|
308 |
620 |
764 |
920 |
960 |
600 |
700 |
|
DNRGS-700 |
|
360 |
720 |
930 |
1124 |
1160 |
700 |
800 |
|
DNRGS-800 |
0.75KW |
440 |
880 |
1080 |
1330 |
1420 |
800 |
900 |
|
DNRGS-900 |
|
550 |
1024 |
1250 |
1450 |
1580 |
900 |
1000 |
|
DNRGS-1000 |
|
580 |
1160 |
1450 |
1760 |
1830 |
1000 |
1100 |
|
DNRGS-1100 |
1.1KW |
650 |
1310 |
1670 |
2000 |
2080 |
1100 |
1200 |
|
DNRGS-1200 |
|
710 |
1470 |
1750 |
2080 |
2250 |
1200 |
1300 |
|
DNRGS-1300 |
1.5KW |
780 |
1560 |
1820 |
2160 |
2310 |
1300 |
1400 |
Municipal Projects
Urban sewage treatment plants, stormwater or sewage pumping stations, water intakes for waterworks.
Industrial Wastewater Treatment
Pre-treatment of wastewater from industries such as paper making, textiles, food processing, chemicals, and slaughtering.
Agricultural Applications
Irrigation pumping stations, reservoir intakes, water Intakes.
Power Plants
Hydropower stations, cooling water systems for nuclear/thermal power plants.
Industrial Water Recycling and Reuse
Industrial cooling and process water filtration.
